3 Operation and visualization
3.4 Configuration
On calling up the configuration level, the password is requested (factory-set:
9200). It also serves to prevent unauthorized alteration of the configuration.
v Chapter 3.9 “Code number (password entry)”
Window
technology
Like for the other levels, the principle of configuration is also based on menu-
led window technology. Individual menu items can be selected in the win-
dows. The window title describes the contents of the window.
When a menu item has been selected, a further window is opened with new
menu items, until the required parameter is finally reached. If several windows
are open, the window title assists in orientation.
The configuration of the paperless recorder is sub-divided into the following
levels:
v Chapter 4 “Configuration parameters”
Window title
Parameter is inhibited
Parameter can be selected/edited
Current setting
