7 Identifying the instrument version
7.1 Type designation
Paperless recorder for capturing,
visualizing, storing and evaluating measurement data
(1) Basic version
955015/14 paperless recorder with 3 analog inputs
955015/24
paperless recorder with 3 analog inputs
incl. setup and PCA evaluation program
955015/15 paperless recorder with 6 analog inputs
955015/25
paperless recorder with 6 analog inputs
incl. setup and PCA evaluation program
(2) Inputs 1 — 3 (programmable)
xxxx 888 factory-set
(3) Inputs 4 — 6 (programmable)
x x 000 not assigned
x x 888 factory-set
(4) Supply
xxxx 22 20— 53V AC/DC 48—63Hz
xxxx 23 110—240V +10/-15% AC 48—63Hz
(5) Extra codes
xxxx 020 lithium battery for memory backup (ex-factory)
xxxx 021 storage capacitor for memory backup
(on request)
xxxx 260 integrators and counters /
math and logic module
1
xxxx 261 4 logic inputs, 3 relay outputs,
serial interface RS232/RS485
xxxx 264 memory expansion to 2MB
2
xxxx 265 Door with lock (IP54)
xxxx 266 IP65 seal, wide mounting brackets
xxxx 350 universal carrying case TG-35
(1) (2) (3) (4) (5)
Order code - - - / ,...
Order example 955015/14 - 888 - 000 - 23 / 020
3
1. The math and logic module can only be used in conjunction with the
setup program.
2. Memory expansion is only possible with new orders
(not for retrofitting).
3. Extra codes are listed one after another, separated by commas.
