2 Instrument description
10
Opening and
closing the
housing door
2.2 Operating principle and graphic elements
Keys The recorder is operated from eight keys. Three of these have fixed functions,
the other five (softkeys) have menu-dependent functions.
v Chapter 2.1 “Display and controls”
Softkeys The softkey functions appear in the bottom line of the display, as symbols or in
plain language.
The housing door can
be opened or closed
by turning the knob
Status line
Header
