JUMO LOGOSCREEN 500 - Configuration - Interface

4 Configuration parameters
62
4.2.10 Configuration - Interface
4.2.11 Configuration - Fine calibration
Parameter Value/selection Description
Interface type Configuration
➔ Interface
➔ Interface type
RS232,
RS485
Selection of the serial inter-
face (extra code)
Protocol Configuration
➔ Interface
➔ Protocol
MODBUS,
JBUS
Baud rate Configuration
➔ Interface
➔ Baud rate
9600 baud,
19200 baud,
38400 baud
Data format Configuration
➔ Interface
➔ Data format
8-1-none,
8-1-odd,
8-1-even,
8-2-none
Instrument address Configuration
➔ Interface
➔ Instrument address
1 —255
Minimum
response time
Configuration
➔ Interface
➔ Min. response time
0 —500ms
Parameter Value/selection Description
Calibration status Configuration
➔ Fine calibration
➔ Analog input 1 — 6
➔ Calibration
status
Off,
On
A calibration (adjustment)
of the analog measure-
ments can be activated
here. The adjustment is
carried out using a linear
equation.
Actual start value Configuration
➔ Fine calibration
➔ Analog input 1 — 6
➔ Actual
start value
-99999 to 0 to +99999 Start value of the actual
line.
Only active when
calibration status = On.
Set start value Configuration
➔ Fine calibration
➔ Analog input 1 — 6
➔ Set start value
-99999 to 0 to +99999 Start value of the
set line.
Only active when
calibration status = On.
Actual end value Configuration
➔ Fine calibration
➔ Analog input 1 — 6
➔ Actual
end value
-99999 to 1000 to +99999 End value of the actual line.
Only active when
calibration status = On.
Set end value Configuration
➔ Fine calibration
➔ Analog input 1 — 6
➔ Set end value
-99999 to 1000 to +99999 End value of the
set line.
Only active when
calibration status = On.
