JUMO LOGOSCREEN 500 - Configuration - Instrument Data

49
4 Configuration parameters
4.2.2 Configuration - Instrument data
Channel indication Parameters
➔ Diagram view
➔ Channel indication
➔ Analog
input 1 — 6
Yes,
No
“Yes” means that the se-
lected channels are shown
in the header
Paper perforations Parameters
➔ Diagram view
➔ Paper perforations
No,
Yes
“Yes” means that paper
perforations are shown
within the graphic display,
on the left and right
margins of the screen.
Paper perforations can
only be activated and
shown if no event traces
have been selected (signal
type = analog input).
Counter/Int. reset Parameters
➔ Counter/Int. reset
➔ Channel 1 — 6
-999999999 — 0 —
+999999999
The start value for the
counter or integrator can
be entered here. The
current value is not saved.
Count changes are docu-
mented in the event list.
v Chapter 3.3 “Parame-
ter setting”
If password request is acti-
ve, (password “Counter/
Int. reset” > 0), the start va-
lues can only be set if the
password has been en-
tered correctly.
Parameter Value/selection Description
Instrument
name
Configuration
➔ Instrument data
➔ Instrument name
16 characters v Chapter 3.8 “Text input”
Date Configuration
➔ Instrument data
➔ Date and time
➔ Date
any data Input of current date
Time Configuration
➔ Instrument data
➔ Date and time
➔ Time
any time Input of current time
