4 Configuration parameters
56
Input signal Configuration
➔ Counter/Integrator
➔ Count/In. channs.
➔ Channel 1 — 6
➔ Input signal
Off,
Logic inp1 — 4,
Logic channel 1 — 6,
Low alarm 1 — 6,
Low comb. al.,
High alarm 1 — 6,
High comb. al.,
Counter/I al. 1 — 6,
C/I comb. al.,
Comb. alarm,
Memory al.,
Error,
Modbus-Flag
The parameter is only
programmable when
“Counter” or “Operating
time” has been selected
under Function.
Please select which event
is to be counted.
Input signal Configuration
➔ Counter/Integrator
➔ Counter/In. channs.
➔ Channel 1 — 6
➔ Input signal
Analog inp1 — 3 (6) The parameter is only pro-
grammable when “Integra-
tor” has been selected
under Function.
Select which input is to be
integrated.
Weighting
(evaluation)
Configuration
➔ Counter/Integrator
➔ Counter/Int. channs.
➔ Channel 1 — 6
➔ Weighting
-99999 to +1 to +99999 Select the weighting factor
here.
If, for instance, 0.001 is en-
tered, a conversion from
l/sec to m³/sec can be
achieved. If a negative
weighting factor is entered
(e.g. -1), the counter will
count down.
Time base Configuration
➔ Counter/Integrator
➔ Counter/In. channs.
➔ Channel 1 — 6
➔ Time base
Second,
Minute,
Hour,
Day
The parameter is only pro-
grammable when “Integra-
tor” or “Operating time”
has been selected under
Function.
Integrator:
Select the time base for in-
tegrating the selected
channel (e.g. second when
your sensor generates a
signal in liters/sec).
Operating time:
Select the unit used for
counting the time.
Threshold value Configuration
➔ Counter/Integrator
➔ Counter/In. channs.
➔ Channel 1 — 6
➔ Threshold
value
0 — 99999 The parameter is only pro-
grammable when “Integra-
tor” has been selected un-
der Function.
Enter the threshold value
which has to be exceeded
for integration.
