JUMO LOGOSCREEN 500 - Configuration - Measurement storage

57
4 Configuration parameters
Channel name
(line 1)
Configuration
➔ Counter/Integrator
➔ Counter/In. channs.
➔ Channel 1 — 6
➔ Channel name
7 characters
Counter/
The text that has been
entered appears together
with line 2 and the current
count on the recorder
screen (visualization and
event list).
v Chapter 3.2.7 “Coun-
ters / integrators / ope-
rating time”
Channel name
(line 2)
Configuration
➔ Counter/Integrator
➔ Counter/In. channs.
➔ Channel 1 — 6
➔ Channel name
7 characters
Integrx
The text that has been en-
tered appears together
with line 1 and the current
count on the recorder
screen (visualization and
event list).
Unit Configuration
➔ Counter/Integrator
➔ Counter/In. channs.
➔ Channel 1 — 6
➔ Unit
5 characters Enter the unit which is dis-
played on the recorder
screen, together with the
entered text and the cur-
rent count.
Decimal place Configuration
➔ Counter/Integrator
➔ Counter/In. channs.
➔ Channel 1 — 6
➔ Decimal place
Automatic,
X.XXXX, XX.XXX,
XXX.XX, XXXX.X,
XXXXX.
Specify the decimal place
for displaying the count on
the recorder screen.
Counter text Configuration
➔ Counter/Integrator
➔ Counter/In. channs.
➔ Channel 1 — 6
➔ Counter text
Standard text,
Text 1 — 18,
No text
If the counter is increment-
ed (decremented), the text
selected here will appear in
the status line and the
event list.
Alarm Configuration
➔ Counter/Integrator
➔ Counter/In. channs.
➔ Channel 1 — 6
➔ Alarm
➔ Alarm
Off,
Activated
Limit value Configuration
➔ Counter/Integrator
➔ Counter/In. channs.
➔ Channel 1 — 6
➔ Alarm
➔ Limit value
-99999 to 100 to +99999 An alarm is triggered when
the limit is infringed. Using
the parameter Weighting, it
is possible to differentiate
between going above or
going below the limit
(positive weighting factor =
alarm on going above the
limit)
Alarm text Configuration
➔ Counter/Integrator
➔ Counter/In. channs.
➔ Channel 1 — 6
➔ Alarm
➔ Alarm text
Standard text,
Text 1 — 18,
No text
On going above or below
the limit, the text selected
here will appear in the sta-
tus line and the event list.
