JUMO LOGOSCREEN 500 - Configuration - Counter;Integrator (option)

53
4 Configuration parameters
End temperature Configuration
➔Analog inputs
➔ Analog input 1—6
➔ End
temperature
any value Only for sensor types:
current, voltage with linear-
ization for resistance ther-
mometer, thermocouple.
Only for signals which are
not yet linearized.
Scaling start Configuration
➔ Analog inputs
➔ Analog input 1—6
➔ Scaling start
-99999 to 0 to +99999
Scaling end Configuration
➔Analog inputs
➔ Analog input 1—6
➔ Scaling end
-99999 to +100 to +99999
Filter constant Configuration
➔Analog inputs
➔ Analog input 1—6
➔ Filter constant
0.0 to 0.1 to 10.0s
Channel name Configuration
➔Analog inputs
➔ Analog input 1—6
➔ Channel
name
7 characters
Inp. 1
Short designation. It is
shown in the channel line
(header) with bargraph and
scaling.
v Chapter 3.8 “Text input”
Unit Configuration
➔ Analog inputs
➔ Analog input 1—6
➔ Unit
5 characters
%
v Chapter 3.8 “Text input”
Decimal place Configuration
➔ Analog inputs
➔ Analog input 1—6
➔ Decimal place
Automatic,
X.XXXX, XX.XXX,
XXX.XX, XXXX.X,
XXXXX.
Automatic: representation
with max. resolution
Line width Configuration
➔ Analog inputs
➔ Analog input 1—6
➔ Line width
Thin,
Thick
Line width of the measure-
ment curve within the
graphical display
Alarm Configuration
➔Analog inputs
➔ Analog input 1—6
➔ Alarm
➔ Alarm
Off,
Activated
Low limit Configuration
➔Analog inputs
➔ Analog input 1—6
➔ Alarm
➔ Low limit
-99999 to 0 to +99999
High limit Configuration
➔Analog inputs
➔ Analog input 1—6
➔ Alarm
➔ High limit
-99999 to 0 to +99999
Parameter Value/selection Description
