03.09 EN

2 Securing the Truck for Transport

Securing the truck for transport

WARNING!

Accidental movement during transport

Improper fastening of the truck and mast during transport can result in serious acci-

dents.

XLoading must be carried out by specially trained staff in accordance with recom-

mendations contained in Guidelines VDI 2700 and VDI 2703 In each case correct

measurements must be made and appropriate safety measures adopted.

XThe truck must be securely fastened when transported on a lorry or a trailer.

XThe lorry / trailer must have fastening rings.

XUse wedges to prevent the truck from moving.

XUse only tension belts or tie-down straps or with sufficient strength.

Requirements

– Load handler lowered

– Key switch set to OFF

– Key removed, for code lock the O key pressed

– Emergency Disconnect pressed

– Battery disconnected

Tools and Material Required

– Tension belts/tie down straps

Procedure

• Park the truck securely on a lorry or trail-

er.

• Attach at least four tension belts (4,5) to

the mast, 2 on the left and 2 on the right.

The truck can now be transported.
