Jungheinrich EKS 110 User Manual

53
03.09 EN
4.7 Lifting and lowering the operator platform with lift cutout (o)
On trucks with the lift cutout option (o) the operator platform rises to a fixed cutout
height which is less than the maximum lift height.
Lifting
Procedure
• Press the lift button (3) until you reach the fixed cutout height.
• To lift beyond the fixed cutout height, proceed as follows:
• Press and hold down on the lift button (3).
• Now press the two-hand operation button (15) as well.
Lowering
Procedure
• Press the lower button (2). The operator platform lowers.
Z The operator platform does not stop at the fixed cutout height on lowering.
23
15
53
03.09 EN
4.7 Lifting and lowering the operator platform with lift cutout (o)
On trucks with the lift cutout option (o) the operator platform rises to a fixed cutout
height which is less than the maximum lift height.
Lifting
Procedure
• Press the lift button (3) until you reach the fixed cutout height.
• To lift beyond the fixed cutout height, proceed as follows:
• Press and hold down on the lift button (3).
• Now press the two-hand operation button (15) as well.
Lowering
Procedure
• Press the lower button (2). The operator platform lowers.
Z The operator platform does not stop at the fixed cutout height on lowering.
23
15
