Jungheinrich EKS 110 User Manual

03.09 EN
50
4.6 Lifting and lowering in pedestrian touch mode
In pedestrian touch mode lifting and lowering can be operated from either side of the
truck as an optional feature.
On trucks with forks (version L) the entire operator platform rises or lowers with the
forks in pedestrian touch mode lifting/lowering.
On trucks with an auxiliary mast (version Z) the auxiliary mast forks rise or lower in
pedestrian touch mode lifting/lowering.
4.6.1 Lifting and lowering the operator platform (version L)
Lifting
CAUTION!
Risk of trapping
XSteering set straight-ahead.
XThe operator must always stand beside the truck during pedestrian operation.
XThere must be no persons standing between the truck and any obstacles.
XThere must be no persons on the operator platform.
Procedure
• Press the lift button (8) until you reach the desired lift height.
Z For safety reasons the height of the forks is restricted to 625 mm.
Lowering
WARNING!
Ensure there are no other people standing underneath the raised load and driv-
er's cab.
XDo not stand on the load handler.
XDo not lift other people on the load handler.
XInstruct other people to move out of the hazardous area of the truck.
XThe operator must stand outside the geometry of the truck and the load.
Procedure
• Press the lower button (7). The operator platform and forks lower.
03.09 EN
50
4.6 Lifting and lowering in pedestrian touch mode
In pedestrian touch mode lifting and lowering can be operated from either side of the
truck as an optional feature.
On trucks with forks (version L) the entire operator platform rises or lowers with the
forks in pedestrian touch mode lifting/lowering.
On trucks with an auxiliary mast (version Z) the auxiliary mast forks rise or lower in
pedestrian touch mode lifting/lowering.
4.6.1 Lifting and lowering the operator platform (version L)
Lifting
CAUTION!
Risk of trapping
XSteering set straight-ahead.
XThe operator must always stand beside the truck during pedestrian operation.
XThere must be no persons standing between the truck and any obstacles.
XThere must be no persons on the operator platform.
Procedure
• Press the lift button (8) until you reach the desired lift height.
Z For safety reasons the height of the forks is restricted to 625 mm.
Lowering
WARNING!
Ensure there are no other people standing underneath the raised load and driv-
er's cab.
XDo not stand on the load handler.
XDo not lift other people on the load handler.
XInstruct other people to move out of the hazardous area of the truck.
XThe operator must stand outside the geometry of the truck and the load.
Procedure
• Press the lower button (7). The operator platform and forks lower.
