Jungheinrich EKS 110 User Manual

33
03.09 EN
8 Pedestrian mode lift
button
o Pedestrian mode optional feature: Lifts the
operator platform and forks.
9 Drive direction pedes-
trian touch mode
o Pedestrian mode optional feature, travel is
continued as operator walks beside in drive
direction (slow travel).
10 Fork direction pedes-
trian touch mode
o Pedestrian mode optional feature, travel is
continued as operator walks beside in forks
direction (slow travel).
11 Driver's display t Displays important travel and lift parameters;
selection and display of steering modes, warn-
ings, incorrect operation notes and service dis-
plays.
12 Emergency Disconnect t The circuit is interrupted, all electrical functions
are cut out and the truck automatically brakes.
13 Controller t Controls the travel direction and speed.
o 2nd control station
14 Steering wheel t Steers the truck.
15 Button:
Two-hand operation
o Releases lifting and travel when pressed (in rail
guidance mode with aisle recognition).
16 Indicator o End of aisle safety device optional feature:
Indicates reduced travel speed
17 Reset button o End of aisle safety device optional feature:
Releases normal travel speed.
18 Key switch and key t Switches control voltage on and off. Removing
the key prevents the truck from being switched
on by unauthorised personnel.
CANCODE keypad o Code lock, replaces the key switch. Switches
control current on and off. Enables truck func-
tions. Change access codes.
ISM access module o Replaces the key switch. Checks the card (or
the transponder). Enables truck functions. Tim-
eout monitoring. Lists the truck users (shifts)
and saves them onto the card. Operational
data acquisition.
19 Emergency Disconnect o Pedestrian mode optional feature: Disconnects
the supply current and deactivates all electrical
functions, causing the truck to brake automati-
cally.
t Standard equipment
o Optional equipment
Item Control / Display Function
33
03.09 EN
8 Pedestrian mode lift
button
o Pedestrian mode optional feature: Lifts the
operator platform and forks.
9 Drive direction pedes-
trian touch mode
o Pedestrian mode optional feature, travel is
continued as operator walks beside in drive
direction (slow travel).
10 Fork direction pedes-
trian touch mode
o Pedestrian mode optional feature, travel is
continued as operator walks beside in forks
direction (slow travel).
11 Driver's display t Displays important travel and lift parameters;
selection and display of steering modes, warn-
ings, incorrect operation notes and service dis-
plays.
12 Emergency Disconnect t The circuit is interrupted, all electrical functions
are cut out and the truck automatically brakes.
13 Controller t Controls the travel direction and speed.
o 2nd control station
14 Steering wheel t Steers the truck.
15 Button:
Two-hand operation
o Releases lifting and travel when pressed (in rail
guidance mode with aisle recognition).
16 Indicator o End of aisle safety device optional feature:
Indicates reduced travel speed
17 Reset button o End of aisle safety device optional feature:
Releases normal travel speed.
18 Key switch and key t Switches control voltage on and off. Removing
the key prevents the truck from being switched
on by unauthorised personnel.
CANCODE keypad o Code lock, replaces the key switch. Switches
control current on and off. Enables truck func-
tions. Change access codes.
ISM access module o Replaces the key switch. Checks the card (or
the transponder). Enables truck functions. Tim-
eout monitoring. Lists the truck users (shifts)
and saves them onto the card. Operational
data acquisition.
19 Emergency Disconnect o Pedestrian mode optional feature: Disconnects
the supply current and deactivates all electrical
functions, causing the truck to brake automati-
cally.
t Standard equipment
o Optional equipment
Item Control / Display Function
