Jungheinrich EKS 110 User Manual

43
03.09 EN
4.2.3 Travel
Requirements
– Truck started up.
– Beyond a lift height of 1200 mm the gates (26) must be closed to enable travel and
lifting (main lift).
– Panels closed and locked correctly.
Procedure
• Press the deadman button (27, 28).
• Set the controller (13) to the required direction. Note the travel direction of the drive
wheel on the driver's display (11).
Z Always travel outside of aisles with the load lowered.
Z The maximum travel speed will depend on the platform and the auxiliary lift heights
(o)
The truck travels in the required direction.
14
11
13
43
03.09 EN
4.2.3 Travel
Requirements
– Truck started up.
– Beyond a lift height of 1200 mm the gates (26) must be closed to enable travel and
lifting (main lift).
– Panels closed and locked correctly.
Procedure
• Press the deadman button (27, 28).
• Set the controller (13) to the required direction. Note the travel direction of the drive
wheel on the driver's display (11).
Z Always travel outside of aisles with the load lowered.
Z The maximum travel speed will depend on the platform and the auxiliary lift heights
(o)
The truck travels in the required direction.
14
11
13

Jungheinrich EKS 110 Specifications

General

Brand	Jungheinrich
Model	EKS 110
Category	Trucks
Language	English
