107
08.11 EN
6.11 Optional equipment for working in areas with heavy accumulation
of dust
When working in areas with high levels of dust (lint, splinters) the Industrial truck can
be fitted with an optional lint filter on the cooler.
CAUTION!
Clogged lint filters can cause fires
XThe lint filter must be cleaned regularly according to how much it is clogged.
Procedure
• Tilt the gas bottle holder back (TFG only).
• Open the two quick releases (143) and
remove the cover (144).
• Remove the (145) lint mesh and clean it.
• Fit the lint mesh back and lock it.
• fit and lock the cover.
• Fold up the gas bottle holder (TFG only).
6.12 Roof window wiper
The roof window wiper is activated by pressing the switch in the dashboard.
Procedure
• Press switch to switch the roof window wiper on.
• Keep pressing the switch to turn the roof window wiper off.
145
144143
143
