08.11 EN
78
4.7 Brakes
WARNING!
Accident risk
The brake pattern of the truck depends
largely on the ground conditions.
XThe driver must be aware of travel route
conditions and them into account when
braking.
XBrake with care to prevent the load from
slipping.
XAllow for increased braking distance
when travelling with an attached load.
XUse the service brake in emergencies.
4.7.1 Service brake
The brake pedal hydraulically actuates
the drum brakes of the front wheels.
When the brake pedal (78) is applied the
drum brakes are applied without
disengaging the transmission.
Applying the slow travel / brake pedal (72)
controls the flow of power in the power
shift gear. This pedal can also be used to
brake gently during crawl speed
operations.
78
72
