08.11 EN
108
6.13 Tilt angle display
NOTE
The current tilt angle is shown in an
additional display that is attached on the
right of the dashboard.
– Green LEDs (146) indicate the vertical
position to the ground.
6.14 Speed reduction
The maximal achievable speed is limited to a preset value. Full motor speed and
power are available while stopped and accelerating. The speed of the motor is not
ramped down until the set maximum speed is reached.
The maximum speed is factory set and can be adjusted by trained and authorised
customer service personnel.
6.15 Reversing Block
The travel direction can only be changed (reversing) if the industrial truck is travelling
at less than 3 km/h. If the driver attempts to change direction without braking at a
faster speed, the system automatically activates idle speed. The required travel level
can only be applied when the speed is reduced accordingly.
The drive cannot be set from neutral to travel if the engine is more than 300 rpm
above idle speed. Travel is only activated when the speed falls below this limit.
6.16 Direction switch mounted to the steering column
The travel direction switch (147) is attached to
the steering column on the left.
When the direction switch is in the centre
position, the gear is in idle / neutral
Procedure
• To select forward gear, push the lever
forward.
• To select reverse gear, push the lever back.
Travel is released in the same way as for the standard version ((see "Travel" in
chapter 4.5)).
146
147
