Jungheinrich TFG 430 User Manual

08.11 EN
22
3.2 Dimensions
*) The data listed in the table corresponds to the standard version.
DFG/TFG 316/320
Description VFG
DFG/TFG 316 DFG/TFG 320
a/2 Safety distance 100 100 mm
h
1
Mast height retracted* 2185 2185 mm
h
2
Free lift* 150 150 mm
h
3
Lift* 3300 3300 mm
h
4
Mast height extended* 3920 3920 mm
h
6
Overhead guard height* 2145 2145 mm
h
7
Seat height* 1049 1049 mm
h
10
Coupling height 380 380 mm
a Mast tilt, fwd.* 7 7 °
ß Mast tilt, back* 7 7 °
l
1
Length, including forks* 3386 3406 mm
l
2
Headlength* 2236 2256 mm
b
1
Overall width* 1080 1080 mm
s/e/l Fork dimensions* 40x100x1150 40x100x1150 mm
m
1
Ground clearance with
load below mast*
120 120 mm
m
2
Ground clearance
centre wheelbase*
130 130 mm
Fork carriage ISO 2328
class / type A, B
2 A 2 A mm
b
3
Fork carriage width 980 980 mm
Ast Working aisle width for
pallets 800 x 1200
longit.
3818 3840 mm
Ast Working aisle width for
pallets 1000 x 1200
traverse
3618 3640 mm
Wa Turning radius 2020 2042 mm
b
13
Smallest turning radius 560 560 mm
x Load distance* 398 398 mm
c Load centre of gravity 500 500 mm
y Wheelbase 1495 1495 mm
