08.11 EN
172
7.6.14 Replace air filter cartridge
DANGER!
A running engine can be dangerous
XCarry out all maintenance work with the engine switched off.
XDo not start the engine if the air filter cartridge is removed.
Replace air filter cartridge
Procedure
• Undo the 2 mounting clamps (180) and
remove the dust collector pot.
• Carefully remove the air filter cartridge from
the filter housing.
Cleaning the filter housing
Procedure
NOTE
A faulty engine can cause malfunctions
XDo not clean the air filter housing with compressed air.
XAlways use a clean cloth to clean the air filter housing.
• Remove the air filter cartridge.
• Thoroughly clean the dust collector pot, to do this remove the dust extraction valve.
• Carefully clean the air filter housing with a clean cloth.
Z There must be no residue from the cloth in the air filter housing.
• Insert the air filter cartridges back in the filter housing.
Z Take care not to damage the air filter cartridges when assembling.
• Fit the rubber element back into the dust collector pot.
• Insert the dust collector pot and secure it with the 2 mounting clamps (180).
7.6.15 Adding window washer system fluid
Procedure
• Make sure there is sufficient window fluid in
the container (181).
• If necessary top up with anti-freeze.
Z Fill with weather-dependent additives.
180
180
181
