175
08.11 EN
Fuses
Checking a fuse
DFG main current
Item Description Electric circuit Rating (A)
55 9F11 t Preheat fuse 70
56 9F8 o Engine running option relay 50
57 9F7 o Ignition on options relay 50
58 9F16 t Key switch 20
59 9F17 t Pre-fuse for F19 20
60 9F19 t 50 A generator 50
t 80 A generator 70
t 120 A generator 120
TFG main current
Item Description Electric circuit Rating (A)
51 9F8 o Engine running option relay 50
52 9F7 o Ignition on options relay 50
53 9F16 t Key switch 20
54 9F17 t Pre-fuse for F19 20
60
9F19
t 50 A generator 50
t 80 A generator 70
t= Series equipment o= Optional equipment
Fuse box for optional equipment (DFG/TFG)
Item Description Electric circuit Rating (A)
45 4F4 o Rotating beacon 7,5
46 9F1 o Windscreen wiper 7,5
47 5F6 o Cabin 15
48 5F1 o Work lights 25
49 5F3 o Reversing lights 15
50 5F5.2 o Road traffic parking light 15
Road traffic system fuse box
Item Description Electric circuit Rating (A)
62 4F5 o Control fuse warning indicator system 10
63 4F6 o Brake light control fuse 10
64 5F4 o Tail lights control fuse 5
65 5F4.1 o Tail lights control fuse 5
66 5F5 o Lighting control fuse 7.5
