27
08.11 EN
DFG/TFG 425/430
Mast table
VDI 3596
Description
Lift h
3
Free lift h
2
425/430
Retracted
height h
1
Extended
height h
4 425/430
Mast
weight (kg)
ZT
2900 150 2115 3510/3670 700
3100 150 2215 3710/3870 720
3300 150 2315 3910/4070 740
3500 150 2415 4110/4270 760
3700 150 2515 4310/4470 780
4000 150 2665 4610/4770 830
4300 150 2865 4910/5070 865
4500 150 2965 5110/5270 885
4700 150 3065 5310/5470 905
5000 150 3215 5610/5770 935
5500 150 3515 6110/6270 995
5800 150 3665 6410/6570 1025
6000 150 3765 6610/6770 1045
ZZ
2900 1480/1380 2080 3500/3600 735
3100 1580/1480 2180 3700/3800 755
3300 1680/1580 2280 3900/4000 780
3500 1780/1680 2380 4100/4200 800
3700 1880/1780 2480 4300/4400 820
4000 2030/1930 2630 4600/4700 850
4300 2230/2130 2830 4900/5000 904
4500 2330/2230 2930 5100/5200 930
DZ
4400 1480/1380 2080 5000/5100 920
4700 1580/1480 2180 5300/5400 950
5000 1680/1580 2280 5600/5700 980
5500 1880/1780 2480 6100/6200 1040
6000 2080/1980 2680 6600/6700 1100
6500 2280/2180 2880 7100/7200 1175
7000 2480/2380 3080 7600/7700 1235
