08.11 EN
58
Item Control /
Display
Function
70 Direction switch t Selects travel direction / neutral position
71 Horn t Activates an audible warning.
72
Slow travel / brake pedal t 1. zone: controls slow travel.
2. zone: applies service brake.
73 Parking brake lever t Applies / releases parking brake
74 Steering wheel t Steering the Industrial truck.
72 Steering column
adjusting lever
t Adjusts the steering column tilt.
76 Key switch t Switches power supply on and off.
Starts and stops the engine.
O - All main circuits are cut out and the key
can be removed.
I - Controls and instruments are switched on.
Engine preheating (diesel only).
II -Starting the motor (automatically returns
to the I position).
77 Options switch t Options
78 Brake pedal t The truck brakes to a halt immediately when
applied.
79 Accelerator pedal t Infinite travel speed control.
80 SOLOPILOT t Operates the following functions:
– Load handler lift/lower
– Mast forward / reverse tilt
– Sideshift left / right (o)
– Auxiliary hydraulics (o)
t= Series equipment o= Optional equipment
