Clearance requirements
•
Cabinet airflow requirements
Table 26 on page 77 provides the cabinet requirements and specifications for the router.
Table 26: Cabinet Requirements and Specifications for the ACX2000 and ACX2100 Router
GuidelinesCabinet Requirement
•
You can mount the router in a cabinet that contains a
19-in. (48.3 cm) rack as defined in Cabinets, Racks,
Panels, and Associated Equipment (document number
EIA-310–D) published by the Electronics Industry
Association (http://www.eia.org).
NOTE: The cabinet must meet the strength
requirements to support the weight of the router.
•
The minimum cabinet size must be able to
accommodate the maximum external dimensions of
the router.
Cabinet size
•
The outer edges of the mounting brackets extend the
width of the chassis to 19 in. (48.3 cm).
•
The minimum total clearance inside the cabinet is 30 in.
(76.2 cm) between the inside of the front door and the
inside of the rear door.
Cabinet clearance
