Page #21 background image
CHAPTER 2
Chassis Components and Descriptions
Chassis Physical Specifications for an MX150 on page 5
Front Panel of an MX150 on page 5
Rear Panel of an MX150 on page 6
Chassis Status LEDs on MX150 on page 7
Network Port and Uplink Port LEDs on MX150 on page 8
Management Port LEDs on MX150 on page 10
Chassis Physical Specifications for an MX150
MX150 chassis is a rigid sheet-metal structure that houses the hardware components.
Table 3 on page 5 summarizes the physical specifications of the MX150 chassis.
Table 3: Physical Specifications for the MX150 Chassis
WeightDepthWidthHeightProduct SKU
9.4 lb (4.3 kg)12 in. (30.5 cm)17.36 in. (44.1 cm)1.72 in. (4.3 cm)MX150
Related
Documentation
Rack Requirements for an MX150 on page 23
Cabinet Requirements for an MX150 on page 24
Front Panel of an MX150
The front panel of an MX150 consists of the following components:
Eight 1-Gigabit Ethernet network ports
Two 1-Gigabit Ethernet RJ-45 access ports or uplink ports
Two 1-Gigabit SFP ports
Two 1/10-Gigabit SFP+ ports
Link (LINK) and status (ST) LEDs for SFP and SFP+ ports
1 Mini-USB Type-B console port
5Copyright © 2017, Juniper Networks, Inc.
