Juniper MX150 - Network Port Connector Pinout Information for an MX150; Table 18: RJ-45 Management Port Connector Pinouts for the MX150; Table 19: Network Port Connector Pinout Information for the MX150

Table 18: RJ-45 Management Port Connector Pinouts for the MX150
DescriptionSignalPin
Transmit/receive data pair 1TRP1+1
Transmit/receive data pair 1TRP1–2
Transmit/receive data pair 2TRP2+3
Transmit/receive data pair 3TRP3+4
Transmit/receive data pair 3TRP3–5
Transmit/receive data pair 2TRP2–6
Transmit/receive data pair 4TRP4+7
Transmit/receive data pair 4TRP4–8
Related
Documentation
Management Port LEDs on MX150 on page 10•
Network Port Connector Pinout Information for an MX150
A network port on an MX150 uses an RJ-45 connector to connect to a device.
The port uses an autosensing RJ-45 connector to support a 10/100/1000Base-T
connection. Two LEDs on the port indicate link activity on the port and the port status.
See “Network Port and Uplink Port LEDs on MX150” on page 8.
Table 19 on page 34 provides the pinout information for the RJ-45 connector. An RJ-45
cable, with a connector attached, is supplied with the switch.
Table 19: Network Port Connector Pinout Information for the MX150
DescriptionSignalPin
Transmit/receive data pair 1
Negative Vport (in PoE models)
TRP1+1
Transmit/receive data pair 1
Negative Vport (in PoE models)
TRP1-2
Transmit/receive data pair 2
Positive Vport (in PoE models)
TRP2+3
Transmit/receive data pair 3TRP3+4
