Table 16: Mini-USB Type-B Console Port Pinout Information for MX150 (continued)
DescriptionSignalPin
GroundGND4
Related
Documentation
MX150 Router Overview on page 3•
• Configuring the Console Port Type (CLI Procedure)
Console Port Connector Pinouts for MX150
The console port (labeled CON) is an RS-232 serial interface that uses an RJ-45 connector
to connect to a console management device. The default baud rate for the console port
is 9600 baud.
Table 17 on page 32 provides the pinout information for the RJ-45 console connector. An
RJ-45 cable and RJ-45 to DB-9 adapter are supplied with the MX150 device.
NOTE: If your laptop or PC does not have a DB-9 male connector pin and you
want to connect your laptop or PC directly to an MX150 device, use a
combination of the RJ-45 cable and RJ-45 to DB-9 adapter supplied with the
device and a USB to DB-9 male adapter. You must provide the USB to DB-9
male adapter.
Table 17: Console Port Connector Pinouts for the MX150
DescriptionSignalPin
Request to sendRTS Output1
Data terminal readyDTR Output2
Transmit dataTxD Output3
Signal groundSignal Ground4
Signal groundSignal Ground5
Receive dataRxD Input6
Data carrier detectDCD Input7
Clear to sendCTS Input8
Related
Documentation
Connecting an MX150 to a Management Console on page 90•
