Table 12: Rack Requirements and Specifications for the MX150 (continued)
GuidelinesRack Requirement
•
Ensure that the rack complies with the standard defined for 19-in. rack as defined in Cabinets,
Racks, Panels, and Associated Equipment (document number EIA-310–D) published by the
ElectronicsIndustryAssociation(http://www.ecianow.org/standards-practices/standards/).
•
Ensure that the rack rails are spaced widely enough to accommodate the device chassis' external
dimensions of 1.72 in. (4.3 cm) height, 17.36 in. (44.1 cm) width, and 12 in. (30.5 cm) depth. The
19-in. rack brackets dimensions are 0.82 in. (2.1 cm) wide, 1.72 in. (4.3 cm) height, and 2.1in. (5.4 cm)
depth. The 23-in. rack brackets dimensions are 3.3 in. (8.4 cm) wide, 1.72 in. (4.3 cm) height, and
8.5 in. (21.6 cm) depth.
•
The rack must be strong enough to support the weight of the device.
•
Ensure that the spacing of rails and adjacent racks allows for the proper clearance around the
device and rack.
Rack size and strength
•
Secure the rack to the building structure.
•
If earthquakes are a possibility in your geographical area, secure the rack to the floor.
•
Secure the rack to the ceiling brackets as well as wall or floor brackets for maximum stability.
Rack connection to
building structure
One pair of mounting brackets for mounting the device on two posts of a rack is supplied
with each device. For mounting the device on four posts of a rack or cabinet, you can
order a four-post rack-mount kit separately.
Related
Documentation
Chassis Physical Specifications for an MX150 on page 5•
• Clearance Requirements for Airflow and Hardware Maintenance for an MX150 on
page 25
• Rack-Mounting and Cabinet-Mounting Warnings on page 132
• Mounting an MX150 on Two Posts in a Rack on page 79
• Mounting an MX150 on Four Posts in a Rack or Cabinet on page 81
Cabinet Requirements for an MX150
You can mount the MX150 in an enclosure or cabinet that contains a four-post 19-in.
open rack as defined in Cabinets, Racks, Panels, and Associated Equipment (document
number EIA-310-D) published by the Electronics Industry Association.
Cabinet requirements consist of:
•
Cabinet size and clearance
•
Cabinet airflow requirements
Table 13 on page 25 provides the cabinet requirements and specifications for the MX150.
Copyright © 2017, Juniper Networks, Inc.24
MX150 3D Universal Edge Router Hardware Guide

Juniper MX150 Specifications

General

Switch type	Managed
Switch layer	L2/L3/L4
Quality of Service (QoS) support	Yes
USB 2.0 ports quantity	1
Installed SFP modules quantity	-
Gigabit Ethernet (copper) ports quantity	12
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	14
Ethernet LAN data rates	10, 100, 480, 800, 1000, 1200, 2500, 3000, 5000, 6000, 10000 Mbit/s
MAC address table	- entries
DHCP features	DHCP client, DHCP server, DHCPv6 client, DHCPv6 server, DHCPv6 snooping
Security algorithms	256-bit AES, 802.1x RADIUS, HTTPS, MD5, SHA-1, SHA-256, SSH, SSL/TLS, TLS
IPv4 & IPv6 features	Dual stack IPv4/IPv6, IPv4/IPv6 access-control list (ACL), IPv6 Telnet, IPv6 portal
Form factor	1U
Product color	Silver
Fanless	No
Flash memory	400000 MB
Internal memory	32768 MB
Processor model	Intel® Xeon®
Operating altitude	0 - 4000 m
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	304.8 mm
Width	440.9 mm
Height	43.7 mm
Weight	4300 g
