Verify that the site meets the requirements described in “Site Preparation Checklist
for MX150” on page 19.
•
Place the desk in its permanent location, allowing adequate clearance for airflow and
maintenance, and secure it to the building structure.
•
Read “General Safety Guidelines and Warnings” on page 121, with particular attention
to “Chassis Lifting Guidelines for MX150” on page 130.
•
Ensure that you have the four rubber feet to stabilize the chassis on the a desk or other
level surface (provided in the accessory box in the router carton)
To mount an MX150 on a desk or other level surface:
1. Remove the device from the shipping carton (see “Unpacking an MX150” on page 73).
2. Turn the chassis upside down on the desk or the level surface where you intend to
mount the device.
3. Attach the rubber feet to the bottom of the chassis as shown in Figure 11 on page 79
4. Turn the chassis right side up on the desk or the level surface.
Figure 11: Attaching Rubber Feet to the MX150
g006771
Related
Documentation
Connecting Earth Ground to an MX150 on page 85•
• Connecting AC Power to an MX150 on page 86
• Clearance Requirements for Airflow and Hardware Maintenance for an MX150 on
page 25
Mounting an MX150 on Two Posts in a Rack
You can mount an MX150 on two posts of a 19-in. rack (either a two-post or a four-post
rack).
NOTE: If you need to mount the MX150 in a recessed position on either a
two-post rack or a four-post rack, you can use the 2-in.-recess front brackets
provided in the separately orderable four-post rack-mount kit.
