Juniper MX150 Hardware Guide

Table 19: Network Port Connector Pinout Information for the MX150 (continued)
DescriptionSignalPin
Transmit/receive data pair 3TRP3-5
Transmit/receive data pair 2
Positive Vport (in PoE models)
TRP2-6
Transmit/receive data pair 4TRP4+7
Transmit/receive data pair 4TRP4-8
Related
Documentation
MX150 Router Overview on page 3•
RJ-45 to DB-9 Serial Port Adapter Pinout Information for an MX150
The console port is an RS-232 serial interface that uses an RJ-45 connector to connect
to a management device such as a PC or a laptop. If your laptop or PC does not have a
DB-9 male connector pin and you want to connect your laptop or PC to an MX150, use
a combination of the RJ-45 to DB-9 female adapter supplied with the switch along with
a USB to DB-9 male adapter.
Table 20 on page 35 provides the pinout information for the RJ-45 to DB-9 serial port
adapter.
Table 20: RJ-45 to DB-9 Serial Port Adapter Pinout Information
SignalDB-9 PinSignalRJ-45 Pin
CTS8RTS1
DSR6DTR2
RXD2TXD3
GND5GND4
TXD3RXD6
DTR4DSR7
RTS7CTS8
Related
Documentation
• Connecting an MX150 to a Management Console on page 90
35Copyright © 2017, Juniper Networks, Inc.
Chapter 7: Port and Pinout Specifications

Juniper MX150 Specifications

General

Switch type	Managed
Switch layer	L2/L3/L4
Quality of Service (QoS) support	Yes
USB 2.0 ports quantity	1
Installed SFP modules quantity	-
Gigabit Ethernet (copper) ports quantity	12
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	14
Ethernet LAN data rates	10, 100, 480, 800, 1000, 1200, 2500, 3000, 5000, 6000, 10000 Mbit/s
MAC address table	- entries
DHCP features	DHCP client, DHCP server, DHCPv6 client, DHCPv6 server, DHCPv6 snooping
Security algorithms	256-bit AES, 802.1x RADIUS, HTTPS, MD5, SHA-1, SHA-256, SSH, SSL/TLS, TLS
IPv4 & IPv6 features	Dual stack IPv4/IPv6, IPv4/IPv6 access-control list (ACL), IPv6 Telnet, IPv6 portal
Form factor	1U
Product color	Silver
Fanless	No
Flash memory	400000 MB
Internal memory	32768 MB
Processor model	Intel® Xeon®
Operating altitude	0 - 4000 m
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	304.8 mm
Width	440.9 mm
Height	43.7 mm
Weight	4300 g
