CHAPTER 7
Port and Pinout Specifications
•
Mini-USB Type-B Console Port Specifications for an MX150 on page 31
•
Console Port Connector Pinouts for MX150 on page 32
•
USB Port Specifications for an MX150 on page 33
•
Management Port Connector Pinout Information for an MX150 on page 33
•
Network Port Connector Pinout Information for an MX150 on page 34
•
RJ-45 to DB-9 Serial Port Adapter Pinout Information for an MX150 on page 35
Mini-USB Type-B Console Port Specifications for an MX150
The MX150 has two console ports: an RJ-45 port, and a Mini-USB port.
By default, the RJ-45 port is set as the active console port. It can display all the early boot
and low-level message output and you can access the device through this port in the
debugger prompt.
The Mini-USB port is the passive console port. You can change the status of the port to
active or passive using the port-type configuration statement. See Configuring the Console
Port Type (CLI Procedure).
The Mini-USB console port uses a Mini-B plug (5-pin) connector to connect to a console
management device. The default baud rate for the console port is 9600 baud.
Table 16 on page 31 provides the pinout information of the Mini-USB Type-B console
port.
Table 16: Mini-USB Type-B Console Port Pinout Information for MX150
DescriptionSignalPin
+5 VDCVCC1
Data -D-2
Data +D+3
N/C, GND, or used as an attached device presence indicatorN/CX
