Juniper MX150 - Standards Supported by These Cables; Mx150

Table 23: SFP+ Direct Attach Copper Cable Specifications (continued)
ValueSpecificationModel Number
10-Gbps full-duplex serial transmissionRateEX-SFP-10GE-DAC-5M
SFP+ passive Twinax cable assemblyConnector type
3.3 VSupply voltage
0.57 WPower consumption (per end)
–40° C through 85° CStorage temperature
TwinaxCable type
24 AWGWire AWG
1 in. (2.54 cm)Minimum cable bend radius
100 ohmsCable characteristic impedance
2% maximumCrosstalk between pairs
1.31 nsec/ftTime delay
5 mLength
Standards Supported by These Cables
The cables comply with the following standards:
•
SFP mechanical standard SFF-843—see ftp://ftp.seagate.com/sff/SFF-8431.PDF .
•
Electrical interface standard SFF-8432—see ftp://ftp.seagate.com/sff/SFF-8432.PDF .
•
SFP+ Multi-Source Alliance (MSA) standards
Related
Documentation
Pluggable Transceivers Supported on MX150 on page 37•
• Installing a Transceiver in an MX150 on page 103
• Removing a Transceiver from an MX150 on page 101
Cable Specifications for Console and Management Connections for the MX150
Table 24 on page 66 lists the specifications for the cables that connect the MX150 to a
management device.
