Figure 2: 3G USB Modem with USB Protection Cover
g033622
Table 7 on page 11 lists the components of the 3G USB modem with USB protection
cover.
Table 7: 3G USB Modem with USB Protection Cover Components
ComponentNumber
USB mount top cover1
USB modem2
USB mount (magnetic/non-magnetic)3
USB mount base4
Lock5
Related
Documentation
Installing a 3G USB Modem in the SRX110 Services Gateway USB Port on page 67•
• SRX110 Services Gateway 3G-WAN USB Port Physical Specifications on page 32
• Configuring the 3G USB Modem on the SRX110 Services Gateway on page 102
