Juniper SRX110 H2 User Manual

3. Select the COM port to which the modem is connected (for example, COM1).
4. Configure the port settings shown in Table 40 on page 78.
Table 40: Port Settings for Connecting to the CLI at User End
ValuePort Setting
9600Bits per second
8Data bits
NoneParity
1Stop bits
NoneFlow control
5. In the HyperTerminal window, enter AT.
For more information on the AT commands, see the following topics:
•
Initial Configuration for Security Devices
•
Monitoring and Troubleshooting for Security Devices
An OK response verifies that the modem can communicate successfully with the COM
port on the PC or laptop.
6. Dial the modem that is connected to the console port on the services gateway by
entering ATDT remote-modem-number. For example, if the number of the modem
connected to the console port on the services gateway is 0013033033030, enter ATDT
0013033033030.
The services gateway login prompt appears.
7. Log in as the user root. No password is required at initial connection, but you must
assign a root password before committing any configuration settings.
Related
Documentation
• Connecting the Modem at the SRX110 Services Gateway End on page 76
• Connecting the Modem to the Console Port on the SRX110 Services Gateway on page 77
• SRX110 Services Gateway Software Configuration Overview on page 83
Copyright © 2015, Juniper Networks, Inc.78
SRX110 Services Gateway Hardware Guide for H2 Model Numbers

Juniper SRX110 H2 Specifications

General

Form Factor	Desktop
VPN Throughput	65 Mbps
Maximum Concurrent Sessions	16, 000
Memory	1 GB DRAM
Flash Memory	256 MB
Power Supply	External AC adapter
Humidity	10% to 90% non-condensing
Weight	2.5 lbs
Operating Temperature	32°F to 104°F (0°C to 40°C)
Ports	8 x 10/100/1000BASE-T
