CHAPTER 13
Providing Power to the SRX110 Services
Gateway
•
Connecting the SRX110 Services Gateway to the Power Supply on page 79
•
Powering On the SRX110 Services Gateway on page 80
•
Powering Off the SRX110 Services Gateway on page 81
Connecting the SRX110 Services Gateway to the Power Supply
To connect the device to the power supply:
CAUTION: Before connecting the device to the power supply, attach an ESD
strap to an ESD point and place the other end of the strap around your bare
wrist.
NOTE: If you are installing your services gateway on a desk, ensure that your
device is adequately grounded using the grounding point on the back panel
of the chassis.
1. Plug the DC connector end of the power cable into the power connector on the back
of the device (see Figure 26 on page 80).
2. Plug the AC adapter end of the power cable into an AC power outlet.
79Copyright © 2015, Juniper Networks, Inc.
