Juniper SRX110 H2 User Manual

CHAPTER 6
Cable Specifications and Pinouts
•
Interface Cable and Wire Specifications for the SRX110 Services Gateway on page 41
•
RJ-45 Connector Pinouts for the SRX110 Services Gateway Ethernet Port on page 42
•
RJ-45 Connector Pinouts for the SRX110 Services Gateway Console Port on page 43
•
RJ-11 Connector Pinouts for the SRX110 Services Gateway on page 44
Interface Cable and Wire Specifications for the SRX110 Services Gateway
Table 22 on page 41 lists the specifications for the cables that connect to ports.
Table 22: Cable and Wire Specifications for Ports
Device Receptacle
Maximum
LengthCable/Wire RequiredCable SpecificationPort
RJ-456 ft
(1.83 m)
One 6 ft (1.83 m) length
with DB-9/RJ-45
connectors
RS-232 (EIA-232)
serial cable
Console
port
RJ-45328 ft
(100 m)
One 15 ft (4.57 m)
length with RJ-45/RJ-45
connectors
CAT-5e (Category 5)
cable or equivalent
suitable for
100BASE-T
operation
Ethernet
port
•
For
VDSL/ADSL-POTS:
RJ-11
•
For
VDSL/ADSL-ISDN:
RJ-45
18K ft
(5.486K
m)
•
For
VDSL/ADSL-POTS:
One 10 ft (3.048 m)
with RJ-11 connector
•
For
VDSL/ADSL-ISDN:
One 10 ft (3.048 m)
with RJ-45 connector
•
For
VDSL/ADSL-POTS:
RJ-11 cable
•
For
VDSL/ADSL-ISDN:
RJ-11/RJ-45 cable
VDSL2
port
Related
Documentation
RJ-45 Connector Pinouts for the SRX110 Services Gateway Ethernet Port on page 42•
• RJ-45 Connector Pinouts for the SRX110 Services Gateway Console Port on page 43
• RJ-11 Connector Pinouts for the SRX110 Services Gateway on page 44
41Copyright © 2015, Juniper Networks, Inc.

Juniper SRX110 H2 Specifications

General

Form Factor	Desktop
VPN Throughput	65 Mbps
Maximum Concurrent Sessions	16, 000
Memory	1 GB DRAM
Flash Memory	256 MB
Power Supply	External AC adapter
Humidity	10% to 90% non-condensing
Weight	2.5 lbs
Operating Temperature	32°F to 104°F (0°C to 40°C)
Ports	8 x 10/100/1000BASE-T
