Juniper SRX110 H2 User Manual

• Preparing the SRX110 Services Gateway for Rack-Mount, Desk-Mount, and Wall-Mount
Installation
• Installing the SRX110 Services Gateway on a Wall on page 65
Installing the SRX110 Services Gateway on a Wall
You can install the SRX110 Services Gateway on a wall.
NOTE: The wall-mounting kit is not shipped with the device and must be
ordered separately.
To install the device on a wall:
1. Place the device on a flat, level surface, with the Juniper Networks logo facing up. The
logo is embossed on the top cover. Ensure that the rubber feet are attached to the
bottom of the chassis.
2. Position a mounting bracket on each side of the chassis as shown in
Figure 19 on page 65.
Figure 19: SRX110 Services Gateway Wall Installation — Attaching the
Mounting Brackets
g033615
Table 35 on page 65 lists the parts to use to install the SRX110 Services Gateway on
a wall. The numbers in Figure 19 on page 65 correspond to the numbers in
Table 35 on page 65.
Table 35: SRX110 Services Gateway Wall Installation Parts
PartNumber
Mounting brackets1
Screws (mounting bracket)2
3. Use a Phillips (+) screwdriver, number 1, to install the screws that secure the mounting
brackets to the chassis.
4. If you are using wall anchors to support the chassis, install two pairs of anchors on
the wall.
65Copyright © 2015, Juniper Networks, Inc.
Chapter 10: Installing the Services Gateway

Juniper SRX110 H2 Specifications

General

Form Factor	Desktop
VPN Throughput	65 Mbps
Maximum Concurrent Sessions	16, 000
Memory	1 GB DRAM
Flash Memory	256 MB
Power Supply	External AC adapter
Humidity	10% to 90% non-condensing
Weight	2.5 lbs
Operating Temperature	32°F to 104°F (0°C to 40°C)
Ports	8 x 10/100/1000BASE-T
