To ground the device:
1. Connect the grounding cable to a proper earth ground.
2. Verify that a licensed electrician has attached the cable lug to the grounding cable.
3. Place the grounding cable lug over the grounding point on the upper rear of the chassis.
4. Secure the grounding cable lug to the grounding point with the screw. Apply between
6 in.-lb (0.67 Nm) and 8 in.-lb (0.9 Nm) of torque to the screws.
5. Dress the grounding cable, and verify that it does not touch or block access to the
services gateway components and that it does not cause a tripping hazard.
NOTE: The deviceshouldbe permanentlyconnectedto ground during normal
operation.
Related
Documentation
• Connecting the SRX110 Services Gateway to the Power Supply on page 79
• Connecting and Organizing the SRX110 Services Gateway Interface Cables on page 75
• SRX110 Services Gateway Grounding Specifications on page 71
• Powering On the SRX110 Services Gateway on page 80
• Powering Off the SRX110 Services Gateway on page 81
• SRX110 Services Gateway General Safety Guidelines and Warnings on page 131
