• Requirements and Specifications for 2.4-GHz Radios on a WLA532E Access Point on
page 31
• Requirements and Specifications for 5-GHz Radios on a WLA532E Access Point on
page 32
External Antenna Configurations for the WLA532E Access Point
The Juniper Networks Wireless LAN Access Point WLA532E supports 3 external antennas
with a maximum gain of 11dBi at 2.4GHz and 25.5dBi at 5GHz.
The labeled ports enable single band connection operations such as distributed antenna
system (DAP) and AP plus mesh applications with combinations. See Table 3 on page 8
and Table 4 on page 8 for antenna configurations.
Table 3: Single Band Antenna Configurations for 2.4GHz and 5GHz Radios
3x3 only2x2 only1x1 and 2x2 combo1x1 only
Port 1+2+3 for either 2.4GHz
or 5GHz but not both
Ports 1 and 2 for 5GHz OR
Ports 2 and 3 for 2.4GHz
Port 2 for 5GHz + Ports 1 and 3 for
2.4GHz OR Port 3 for 2.4GHz + Ports 1
and 2 for 5GHz
Port 2 for 5GHz and/or
Port 3 for 2.4GHz
Table 4: Dual Band Antenna Configurations for 2.4GHz and 5GHz Radios
3x32x21x1
Port 1+2+3 for both 2.4GHz or 5GHzPorts 1 and 2 for 5GHz and/or Ports 2 and 3
for 2.4GHz
Port 2 for 5GHz and/or Port 3 for
2.4GHz
Related
Documentation
WLA532E Antenna Models on page 7•
• Requirements and Specifications for 2.4-GHz Radios on a WLA532E Access Point on
page 31
• Requirements and Specifications for 5-GHz Radios on a WLA532E Access Point on
page 32
Status LEDs on a WLA532E Access Point
The Juniper Networks Wireless LAN Access Point WLA532E has three status LEDs that
glow in green, red and amber colors to indicate the status of the access point, see Table
5 on page 9.
Copyright © 2012, Juniper Networks, Inc.8
WLA532E Access Point Hardware Documentation
