Figure 20: Earthquake Safety Stability Screws
5. Rotate the locking bracket on the legacy mounting bracket adapter into an open
position by pushing the left metal tab down. See Figure 21 on page 59.
Figure 21: Rotating the Locking Bracket into an Open Position
6. Align the four legacy mounting bracket adapter alignment pins to the matching holes
on the universal mounting bracket and push up so the brackets meet. See Figure 22
on page 59.
Figure 22: Aligning the Legacy Mounting Bracket Adapter Alignment Pins
to the Universal Bracket Holes
7. Rotate the locking bracket into a locked position by pushing the right metal tab down.
See Figure 23 on page 60.
