Juniper WLA Series - Figure 33: Pull the Category 5 Cable through the Wall Bracket; Figure 34: Use M3 or 6-32 Wall Anchors to Secure the Bracket to Anchors

Figure 33: Pull the Category 5 Cable Through the Wall Bracket
3. Install the bracket to the anchors using M3 or 6-32 wall anchors (see Figure 34 on
page 67).
Figure 34: Use M3 or 6-32 Wall Anchors to Secure the Bracket to Anchors
4. Align the faceplate with the installed wall-mount bracket and secure the faceplate
using the two provided flat-tip screws and the screwdriver (see Figure 35 on page 68).
67Copyright © 2012, Juniper Networks, Inc.
Chapter 7: Installing and Connecting the Access Point
