CHAPTER 5
Requirements and Specifications
•
Requirements and Specifications for 2.4-GHz Radios on a WLA532E Access
Point on page 31
•
Requirements and Specifications for 5-GHz Radios on a WLA532E Access
Point on page 32
Requirements and Specifications for 2.4-GHz Radios on a WLA532E Access Point
The 2.4-GHz band radio is operational from channels 1 through 14 in legacy IEEE standard
802.11bg or in IEEE 802.11n 3x3 from single to three spatial streams of 20 MHz channel
modes. At an MCS0 data rate, it provides 17 dBm transmit power per chain and has a
receive sensitivity of -89 dBm. At an MCS23 data rate, it provides 11 dBm transmit power
per chain and has a receive sensitivity of -69 dBm. The 2.4-GHz radio consumes a
maximum power rate of 2.75W.
Each antenna connector on the WLA532E can support any external single or dual band
elements. The access point has been designed to maximize isolation between all
antennas. For 5-GHz and 2.4-GHz concurrent operation, the antenna can support a
co-band isolation of -15dB at 2.4-GHz and -30dB at 5-GHz.
Table 2 on page 7 lists the supported antenna models.
Table 9: WLA532E Antenna Models
Vertical BWHorizontal BWGainType
Juniper Model
Number
5GHz2.4GHZ5GHz2.4GHZ5GHz2.4GHZ
60°60°360°360°4dBi3dBiOmni (Paddle)
Non-Plenum
WLA-ANT-7360P-IN
15°22°360°360°8dBi6dBiOmniANT-7360A-OUT
60°70°55°75°10.7dBi8dBiPanelANT-77555-OUT
31Copyright © 2012, Juniper Networks, Inc.
