Black Toe
Process
the dark areas according to the balance of
bright and dark areas in the image to adjust the
overall balance of contrast.
For altering the gain of dark areas. Adjust this item
according to the condition of the captured video
signals.
0
Stretch:
Increases the gain of dark areas in an image to
stretch the signals of these areas only, thereby
showing the contrast between bright and dark
areas more clearly.
Specify the amount of stretch with
[Stretch
Level].
0
Normal:
Normal condition.
0
Compress:
Compresses the gain of dark areas to increase
the contrast when the entire image appears
bright and contrast is weak. Specify the
compression amount with [Compress Level].
[Setting Values: Stretch, RNormal, Compress]
Memo :
0
This item cannot be configured when [Color
Space] is set to “J-Log1” or “HLG”.
0
This item cannot be configured when [Infrared]
is set to “On”.
9
Stretch Level
Stretch amount increases when a larger value is
specified.
[Setting Values: 5 to 1 (R 3)]
Memo :
0
This item is displayed only when
[Black Toe] is
set to “Stretch”. Otherwise, this item appears as
“---” and cannot be selected.
0
This item cannot be configured when [Color
Space] is set to “J-Log1” or “HLG”.
0
This item cannot be configured when [Infrared]
is set to “On”.
9
Compress Level
Compression amount increases when a larger
value is specified.
[Setting Values: 5 to 1 (R 3)]
Memo :
0
This item is displayed only when
[Black Toe] is
set to “Compress”. Otherwise, this item appears
as “---” and cannot be selected.
0
This item cannot be configured when [Color
Space] is set to “J-Log1” or “HLG”.
0
This item cannot be configured when [Infrared]
is set to “On”.
Knee
For specifying the “Knee” operation, which
compresses
video signals beyond a certain level to
show the gradation of the highlighted portion. To
check the gradation of a bright area, set to “Manual”
and adjust the knee point (starting point of knee
operation) manually.
0
Manual:
Enables
manual adjustment of knee point using
[Level].
0
Auto:
Adjusts the knee point automatically according
to the luminance level.
[Setting Values: Manual, RAuto]
Memo :
0
This item cannot be configured when
[Color
Space] is set to “J-Log1” or “HLG” and when
[Gamma] is set to “Cinema 2”.
0
This item cannot be configured when [Infrared]
is set to “On”.
9
Level
For setting the starting point (knee point) of knee
compression when [Knee] is set to “Manual
”.
[Setting Values: 100.0%, 97.5%, R95.0%, 92.5%,
90.0%, 87.5%, 85.0%, 82.5%, 80.0%, 77.5%,
75.0%, 72.5%, 70.0%]
Memo :
0
This item cannot be configured when
[Knee] is
set to “Auto”.
0
This item cannot be configured when [Color
Space] is set to
“J-Log1” or “HLG” and when
[Gamma] is set to “Cinema 2”.
0
This item cannot be configured when
[Infrared]
is set to “On”.
Camera Process Menu
121
