JVC GY-HC500E - Setting Distribution

Setting Distribution
1
Set the [Record Format] according to the
resolution
and frame rate of the video to be
distributed.
For details on the [Record Format] settings,
please refer to [Distributable [Record Format]
and [Live Streaming Set] Combinations]
(A P 216).
Memo :
0
Live streaming cannot be performed in the
following cases.
0
When [System] B [Record Set
] B [Record
Format] B [System] is set to other than “HD”
or “SD”
0
When [System] B [Record Set
] B [Record
Format] B[WFrame Rate] is set to “24p”
2
Set the Resolution and Frame & Bit Rate for
the video to be distributed.
Specify the settings in [Network] B [Live
Streaming].
(A P
140 [Live Streaming Item] )
3
Specify the distribution protocol and
related items.
Specify the distribution protocol and related
items in
[Network] B [Live Streaming] B
[Streaming Server].
(A P141 [ Streaming Server ] )
4
Select the server for live streaming.
Select the distribution server in [Network] B
[Live Streaming
] B [Server].
Distributable [Record Format] and [Live Streaming Set] Combinations
0
When [
Optional Adapter] is configured to “Disable” (H.264 streaming)
.
MPEG2-TS/UDP MPEG2-TS/TCP MPEG2-TS/RTP RTSP/RTP ZIXI, SRT(*1) RTMP RTMPS Facebook Live YouTube Live MPEG2-TS/UDP MPEG2-TS/TCP MPEG2-TS/RTP RTSP/RTP ZIXI, SRT RTMP Facebook Live YouTube Live MPEG2-TS/UDP MPEG2-TS/TCP MPEG2-TS/RTP RTSP/RTP ZIXI, SRT RTMP
24 Mbps
60p, 50p
1920 x 1080
60i, 50i 30p, 25p
20 Mbps
16 Mbps
12 Mbps
8 Mbps
5 Mbps
3 Mbps
1.5 Mbps
0.8 Mbps
0.3 Mbps
Resolution
Frame Rate
Ty p e
Bit
Rate
*
R: Distributable
o: Distributable when
[Format] is configured as follows.
0
QuickTime(H.264), Exchange (U model)
0
MP4(H.264) (E model)
J: When [Format] is configured to “QuickTime(MPEG2)” or “MXF(MPEG2)”, configuring [Time
Stamp] to “On” or configuring [Overlay Function] to “Enable” disables distribution. A
*1 : Distribution at a bit rate of 12 Mbps is possible when [FEC] is configured to “Off”.
216
Performing Live Streaming
Network
