JVC GY-HC500E - Specifications

Specifications
General
Item Description
Power DC 12 V
Power
consumption
Approx. 24.0 W
(When recording in the factory
default settings using the
viewfinder.)
Mass
Approx. 3.6 kg
(With battery attached)
Allowable operating
temperature
0 °C to 40 °C (32 °F to 104 °F)
Allowable operating
humidity
30 %RH to 80 %RH
Allowable storage
temperature
-20 °C to 50 °C (-4 °F to 122 °F)
Built-in wireless
LAN
A
IEEE802.11a/b/g/n/ac
(2.4 GHz/5 GHz band)
Encryption method: WPA2
U
model
2.4 GHz Ch1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11
5 GHz
USA
Ch36, 40, 44, 48, 52, 56, 60, 64,
100, 104, 108, 112, 116, 120,
124, 128, 132, 136, 140, 149,
153, 157, 161, 165
5 GHz
CANADA
Ch36, 40, 44, 48, 52, 56, 60, 64,
100, 104, 108, 112, 116, 132,
136, 140, 149, 153, 157, 161,
165
E
model
2.4 GHz Ch1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11,
12, 13
5 GHz
Outside
Russia
Ch36, 40, 44, 48, 52, 56, 60, 64,
100, 104, 108, 112, 116, 120,
124, 128, 132, 136, 140
5 GHz
Russia
Ch36, 40, 44, 48, 52, 56, 60, 64,
132, 136, 140, 149, 153, 157,
161, 165
Terminal Section
Video/Audio
Item Description
[SDI OUT] terminal (480i or 576i: Downconverted 720p/1080i/
1080p: embedded audio), BNC (unbalanced)
3G-SDI,
HD-SDI,
SD-SDI
Compliant with SMPTE ST424,
Compliant with SMPTE ST292,
Compliant with SMPTE ST259
3G-SDI,
HD-SDI,
SD-SDI
Embedded
audio
standard
Compliant with SMPTE ST299,
Compliant with SMPTE ST299,
Compliant with SMPTE ST272
[HDMI] output
terminal
Type A
[INPUT 1/INPUT 2] Terminal (XLR 3-pin)
[MIC]
-50 dBu, 3 kK, XLR (balanced),
+48 V output (phantom power
supply)
[LINE]
+4 dBu, 10 kK, XLR (balanced)
[AUX] terminal
-22 dBu, 10 kK, 3.5 mm stereo
mini jack (unbalanced)
[x] Terminal
Φ3.5 mm stereo mini jack
256
Specifications
Others
