KAESER EPC Series User Manual

Model Horizontal air receiver
Weight [kg]
Vertical air receiver
Weight [kg]
EPC 230–2–100 — —
EPC 230–2–250 — —
EPC 420–2–250 — —
EPC 550–2–250 — —
EPC 550–2–350 — —
EPC 750–2–500 280/—* 325/—*
EPC 1000–2–500 285/—* 325/—*
* Machine with sound enclosure
Tab. 4 Weight
2.4 Compressor Block
Model Theoretical displace‐
ment [l/min]
Delivery at 12 bar
[l/min]
Number of cylinders
KC 236-2 — — —
KC 420-2 — — —
KC 550-2 — — —
KC 750-2 750 610 2
KC 1000-2 1000 820 2
Tab. 5 Compressor block specification
2.5 Ambient Conditions
Installation
Maximum altitude AMSL*
[m]
1000
Permissible ambient tem‐
perature [°C]
5–35
* Higher altitudes are permissible only after consultation with the manufacturer.
Tab. 6 Ambient Conditions
2.6 Ventilation
The values given are minimum guide values.
Model
Inlet aperture (Z) [m
2
] Exhaust fan (A)* [m
3
/h]
EPC 230–2–100 — —
EPC 230–2–250 — —
*Forced ventilation: required airflow for static ventilator thrust at maximum duty cycle [ΔT 10 K]
2 Technical Specification
2.4 Compressor Block
4
Service Manual 2-stage piston compressor
EPC No.: 9_9431_02 E
