2.9 Sound pressure level
Operational state:
Operating mode LOAD at rated speed, rated air flow and nominal pressure.
Measurement conditions:
Mean sound pressure level at 1 m distance to EN ISO 2151
Model Sound pressure level [dB(A)] Sound pressure level with enclo‐
sure
[dB(A)]
EPC 230–2–100
EPC 230–2–250
EPC 420–2–250
EPC 550–2–250
EPC 550–2–350
EPC 750–2–500 80/80*
EPC 1000–2–500 82/82*
* Sound pressure level for machines with vertical air receivers
Tab. 12 Sound pressure level
2.10 Motor power and speed
Read off the enclosure protection rating from the motor nameplate and enter in the table:
Rated power
[kW]
Synchronous
speed [min
-1
] (50
Hz)
Synchronous
speed [min
-1
] (60
Hz)
Degree of pro‐
tection
KC 236-2 1.7
KC 420-2 3.0
KC 550-2 4.0
KC 750-2 5.5 1500 1800
KC 1000-2 7.5 1500 1800
Tab. 13 Power and speeds
Permissible starting frequency
Read-off the permissible starting frequency of the motor from the table below.
Rated power [kW] Permissible starting frequency [1/h]
1.7
3.0
4.0
5.5 15
2 Technical Specification
2.9 Sound pressure level
6
Service Manual 2-stage piston compressor
EPC No.: 9_9431_02 E
