Feature Chassis Stationary
Height adjustment with without –
Actual total weight [kg]*
Permissible axle load [kg] 1900 1900 –
* Enter here for reference, the actual total weight taken from the nameplate.
Tab. 25 Mass of the machine
2.4.2 Tyres
Characteristic/marking Value
Dekkdimensjon 195 R 14C
Maximum and recom‐
mended tyre pressure
[bar]
4.5
Wheel bolts M 12 x 1.5
Tab. 26 Tyres
2.4.3 Wheel nut/bolt tightening torque
Fixing medium Thread Wrench size Torque [Nm]
Wheel bolt M 12 x 1.5 19 90
Tab. 27 Wheel nut/bolt tightening torque
2.4.4 Towbar tightening torque
Components Thread Strength category Torque [Nm]
Ball coupling M16 8.8 210
Towing eye M16 8.8 210
Towbar M20 10.9 540–560
M24 8.8 670–690
Tab. 28 Towbar tightening torque
2.5 Compressor
2.5.1 Working pressure and FAD
Maximum working pressure [bar] 7 8.6 10 12 14
SIGMA airend 29-G 27-G
Free air delivery [m
3
/min]
11.1 10.1 9.5 8.2 7.3
Tab. 29 Working pressure and FAD
2 Technical Specifications
2.5 Compressor
10
Service manual Portable compressor
M122 No.: 9_6974 20 E
