Do not use a standard coolant / antifreeze that only meets the requirements of ASTM D3306.
Such coolants are intended only for light use in vehicles and could shorten the useful life of
the engine.
The engine service manual gives further information on coolant application.
2.6.4 Fluid volumes
Description Fluid volume [litre]
Engine oil 11.0
Fuel 170.0
Coolant 18.0
Tab. 38 Fluid volumes
2.6.5 Batteries
Feature Value
Voltage [V] 24 (2 x 12)
Capacity [Ah] 2 x 80
PTC testing current [A]
(according to EN 50342)
640
Tab. 39 Batteries
Further information Depending on machine equipment, a higher capacity battery may be required. See chapter 2.7.3.
2.7 Options
2.7.1 Option ea, ec
Tool lubricator
Name Temperature range [°C] Fluid volume [l]
Special road breaker lubricant −25 ..... 50 2.5
Tab. 40 Road breaker lubricant recommendation
2.7.2 Option dc
Fresh air filter
Feature Value
Maximum working pressure [bar] 16
Minimum ambient temperature [°C] 1.5
Maximum ambient temperature [°C] 30
Tab. 41 Fresh air filter conditions
2 Technical Specifications
2.7 Options
14
Service manual Portable compressor
M122 No.: 9_6974 20 E
