Sound Pressure Level M122
Guaranties sound pressure level [dB (A)] 76
Tab. 22 Sound pressure level [dB(A)]
2.3.2 Torques
Recommended values for hexagonal bolts of strength category 8.8
Hex-head screws
Thread M6 M8 M10 M12 M14 M16 M18
Torque [Nm] 9,5 23 46 80 127 195 280
Tab. 23 Torques for hex-head screws
2.3.3 Ambient conditions
Positioning Limit value
Maximum altitude amsl* [m] 1000
Minimum ambient temperature [°C] −10
Maximum ambient temperature [°C] +50
* Higher altitudes are permissible only after consultation with the manufacturer.
Tab. 24 Ambient conditions
2.3.4 Additional specifications according to the machine's operating licence
For specifications according to the machine's operating licence, such as:
■
dimensions,
■ track width,
■ footprint,
are to be found in the dimensioned drawing in chapter 13.3.
The dimensional drawings also show the position of the following inlets and outlets:
■
Cooling air inlet
■ Cooling air outlet
■ Compressed air outlet
■ Exhaust
2.4 Chassis
2.4.1 Mass
The values given are the maximum in each case. Actual mass of individual machines are de‐
pendent on equipment fitted (see machine nameplate).
2 Technical Specifications
2.4 Chassis
No.: 9_6974 20 E
Service manual Portable compressor
M122
