Grey or brownish exhaust gas
Meaning
Remedy
Where can I get help?
Special‐
ised
work‐
shop
KAESER
-service
Engine
service
manual
The exhaust contains residues
of hydrocarbons or sulphate.
Have the fuel injection system
checked.
Use an engine oil that produces
low white ash.
X
X
X
Tab. 65
Grey or brownish exhaust gas
9
Fault Recognition and Rectification
9.4
Evaluate faults in the diesel particulate filter
78
Service manual Portable compressor
