6.3.2 Option sd, sh
Fitting a non-adjustable towbar
Fig. 20 Non-adjustable towbar fitted
1 Overrun braking mechanism
2 Brake transfer cable
3 Brake rod
4 Towbar
5 Jockey wheel
6 Sikringstau
7 Parking brake
* not for USA type chassis
1. Open the doors.
2.
Remove the bag with the brake transfer cable and fastenings, unpack and lay out ready.
3. Close the doors.
4. Remove all transport securing items (screw fastenings, duct tape, foam pads) from the towbar
components.
6 Installation
6.3 Fitting the towbar
50
Service manual Portable compressor
M122 No.: 9_6974 20 E
Option sd, sh
